Mid (Dongguan) Intelligent Manufacturing Co., Ltd. is one of the most reliable manufacturers and suppliers of cnc milling aluminum in China, also supports customized service. If you're going to buy high quality cnc milling aluminum made in China, welcome to get quotation and free sample from our factory. For price consultation, contact us.
What are the most common problems in CNC milling of aluminum?
Aluminum is the most commonly used metal in CNC machining. Due to its excellent physical properties, aluminum accounts for approximately 80% of all non-ferrous metal machined parts in the aerospace, semiconductor, and robotics industries.
Even on modern CNC machining centers, errors can occur in the precision CNC milling of aluminum if the process technology and temperature control are inadequate. Three of the most common problems are:
1. Overcutting: When milling deep into the workpiece, if the tool is too long and the spindle speed cannot reach high enough, overcutting can occur.
2. Temperature effects: Due to the principle of thermal expansion and contraction, complex workpieces need to be milled in a temperature-controlled workshop environment.
3. Edge burrs: – Burr problems are more prominent in custom CNC milling of aluminum parts, especially on parts with intersecting holes or internal threads.
4. Stress Effects: Stress can cause deformation in processed products, leading to defective parts. Therefore, for complex products, we need to rough-cut the surface first, then allow it to rest for about 24 hours to fully release stress before proceeding to the second step, finishing. This will increase processing time.
Why Choose MID Precision for CNC Milling of Aluminum?
MID Precision, located in Dongguan, Guangdong Province, China, boasts 30 years of CNC manufacturing experience and a 7,500 square meter factory, serving global aerospace, semiconductor, and robotics OEMs. Our capabilities include:
1. Dimensional tolerances up to ±0.001 mm
2. Complete FAI documentation and Mitutoyo CMM reports
3. AS9100D aligned quality management system
4. 3-business-day delivery time for prototypes. Please upload your CAD files immediately for DFM review and quotation within 24 hours.
| 牌号 | 布氏硬度 (HB) | 密度 (g/cm³) | 疲劳强度 (MPa) | 抗拉强度 (MPa) | 断裂伸长率 (%) |
| 6061-T6 | 95 | 2.7 | 110 | 310 | 12 |
| 7075-T6 | 150 | 2.8 | 160 | 572 | 11 |
| 5052-O | 47 | 2.68 | 70 | 193 | 18 |
| 2024-T4 | 120 | 2.78 | 140 | 470 | 15 |
| 6067-T6 | 100 | 2.7 | 115 | 330 | 13 |
| 7050-T7451 | 145 | 2.83 | 150 | 524 | 12 |
Aluminum Machining Services
MID offers the highest quality machining services nationwide, guaranteeing consistent quality and fast delivery. We produce over 500 different products monthly for domestic and international orders, meaning our technology and quality control systems are highly mature, our production capacity is almost always sufficient, and our prices remain competitive.
We offer a full range of CNC machining services for aluminum, capable of processing complex aluminum parts from 13 different types of aluminum. Aluminum parts are ideal for applications requiring high strength, corrosion resistance, heat resistance, lightweight, conductivity, and versatility. We can machine a wide variety of parts, from simple "prototypes" to complex, organic geometries, while maintaining tight tolerances. Our aluminum CNC machining services offer up to 13 different post-processing/surface treatment options, including sandblasting, anodizing (milling or turning), electroless nickel plating, and powder coating.
We have outgoing inspection services:
FAI report
100% inspection report
Raw material certificate of conformity
Surface treatment report
CMM report (if required)
Packaging photos
After-sales service available
